Ultra Low Temperature Freezers
SKU: VS-86L108 VS-86L358 VS-86L458 VS-86L568 VS-86L718 VS-86L838
Vacc-Safe ULT Freezers
Select size:
Vacc-Safe DualGuard ULT freezer can be used for the storage and protection of temperature sensitive samples and valuable pharmaceutical products. Using two independent refrigeration systems, if one system fails, the other can maintain the freezer’s temperature uniformly in the -80°C range.
- -86 to -40°C Ultra Low Freezer
- High Precision Temperature Control and Accuracy 0.1°C
- Fast Cabinet Pull Down
- Double Inner Doors
- Racks not included
Ships from Australia
Download Product Brochure: Ultra Low Temperature Freezers
SKU: VS-86L108 VS-86L358 VS-86L458 VS-86L568 VS-86L718 VS-86L838
Vacc-Safe ULT Freezers
Select size:
Vacc-Safe DualGuard ULT freezer can be used for the storage and protection of temperature sensitive samples and valuable pharmaceutical products. Using two independent refrigeration systems, if one system fails, the other can maintain the freezer’s temperature uniformly in the -80°C range.
- -86 to -40°C Ultra Low Freezer
- High Precision Temperature Control and Accuracy 0.1°C
- Fast Cabinet Pull Down
- Double Inner Doors
- Racks not included
Ships from AustraliaKey benefits
Key benefits
VIP Plus
Insulation.
Provides up to 30% more storage capacity than
a conventionally insulated freezer.
Other cold storage units
Smaller storage capacity
Increased Product
Lifespan.
Dissipates heat 20% more effectively to improve life
expectancy of core parts.
Other cold storage units
Retain more heat leading to early part burn-out
Multi-layer Silicone
Sealing Structure.
Provides a tight seal between inner and outer
door for better insulation.
Other cold storage units
Use more energy to retain inner temperature due to poorer seal
Heated Pressure
Equalization Port.
Allows users to re-open the main door quickly.
VS-86L458 VS-86L568 VS-86L718 VS-86L838
Other cold storage units
Main door slow to open
Slim Cabinet
Design.
Slim cabinet design for space utilisation.
Unit can pass through a 750mm wide door.
VS-86L458
Other cold storage units
Bulky cabinet designs take up valuable space
Twin Refrigeration
Systems.
If one system fails, the other can maintain the
freezer’s temperature uniformly in the -80°C range.
VS-86L568 VS-86L718 VS-86L838
Other cold storage units
No backup in place for a system failure to maintain refrigerator temperature
Provides up to 30% more storage capacity than a conventionally insulated freezer.
Other cold storage units
Smaller storage capacity
Dissipates heat 20% more effectively to improve life expectancy of core parts.
Other cold storage units
Retain more heat leading to early part burn-out
Provides a tight seal between inner and outer door for better insulation.
Other cold storage units
Use more energy to retain inner temperature due to poorer seal
Allows users to re-open the main door quickly.
VS-86L458 VS-86L568 VS-86L718 VS-86L838
Other cold storage units
Main door slow to open
Slim cabinet design for space utilisation. Unit can pass through a 750mm wide door.
VS-86L458
Other cold storage units
Bulky cabinet designs take up valuable space
If one system fails, the other can maintain the freezer’s temperature uniformly in the -80°C range.
VS-86L568 VS-86L718 VS-86L838
Other cold storage units
No backup in place for a system failure to maintain refrigerator temperature
Specifications
TEMPERATURE RANGE
-86 TO -40°C TEMPERATURE RANGE
LITRES
VS-86L108: 108 LITRE GROSS CAPACITY
VS-86L358: 358 LITRE GROSS CAPACITY
VS-86L458: 458 LITRE GROSS CAPACITY
VS-86L568: 568 LITRE GROSS CAPACITY
VS-86L718: 718 LITRE GROSS CAPACITY
VS-86L838: 838 LITRE GROSS CAPACITY
DIMENSIONS
VS-86L108: EXTERNAL 955W X 675D X 815H (mm)
VS-86L108: INTERNAL 440W X 435D X 590H (mm)
VS-86L358: EXTERNAL 795W X 855D X 1855H (mm)
VS-86L358: INTERNAL 450W X 583D X 1326H (mm)
VS-86L458: EXTERNAL 885W X 855D X 1990H (mm)
VS-86L458: INTERNAL 595W X 580D X 1310H (mm)
VS-86L568: EXTERNAL 885W X 995D X 1990H (mm)
VS-86L568: INTERNAL 595W X 720D X 1310H (mm)
VS-86L718: EXTERNAL 1030W X 995D X 1990H (mm)
VS-86L718: INTERNAL 740W X 720D X 1310H (mm)
VS-86L838: EXTERNAL 1175W X 995D X 1990H (mm)
VS-86L838: INTERNAL 885W X 720D X 1310H (mm)
SCREEN
LED DISPLAY
POWER OUTPUT
VS-86L108: RATED POWER 480W
VS-86L358: RATED POWER 950W
VS-86L458: RATED POWER 1190W
VS-86L568: RATED POWER 2210W
VS-86L718: RATED POWER 2210W
VS-86L838: RATED POWER 2030W
MACHINE TYPE
FREEZER
WEIGHT
VS-86L108: 113Kg
VS-86L358: 206Kg
VS-86L458: 237Kg
VS-86L568: 286Kg
VS-86L718: 332Kg
VS-86L838: 300Kg
NO. OF SHELVES
VS-86L108: 1
VS-86L358: 3
VS-86L458: 3
VS-86L568: 3
VS-86L718: 3
VS-86L838: 3
CLIMATE CLASS
“N”
PORTHOLE
YES
Specifications
TEMPERATURE RANGE
-86 TO -40°C TEMPERATURE RANGE
LITRES
VS-86L108: 108 LITRE GROSS CAPACITY
VS-86L358: 358 LITRE GROSS CAPACITY
VS-86L458: 458 LITRE GROSS CAPACITY
VS-86L568: 568 LITRE GROSS CAPACITY
VS-86L718: 718 LITRE GROSS CAPACITY
VS-86L838: 838 LITRE GROSS CAPACITY
DIMENSIONS
VS-86L108: EXTERNAL 955W X 675D X 815H (mm)
VS-86L108: INTERNAL 440W X 435D X 590H (mm)
VS-86L358: EXTERNAL 795W X 855D X 1855H (mm)
VS-86L358: INTERNAL 450W X 583D X 1326H (mm)
VS-86L458: EXTERNAL 885W X 855D X 1990H (mm)
VS-86L458: INTERNAL 595W X 580D X 1310H (mm)
VS-86L568: EXTERNAL 885W X 995D X 1990H (mm)
VS-86L568: INTERNAL 595W X 720D X 1310H (mm)
VS-86L718: EXTERNAL 1030W X 995D X 1990H (mm)
VS-86L718: INTERNAL 740W X 720D X 1310H (mm)
VS-86L838: EXTERNAL 1175W X 995D X 1990H (mm)
VS-86L838: INTERNAL 885W X 720D X 1310H (mm)
SCREEN
LED DISPLAY
POWER OUTPUT
VS-86L108: RATED POWER 480W
VS-86L358: RATED POWER 950W
VS-86L458: RATED POWER 1190W
VS-86L568: RATED POWER 2210W
VS-86L718: RATED POWER 2210W
VS-86L838: RATED POWER 2030W
MACHINE TYPE
FREEZER
WEIGHT
VS-86L108: 113Kg
VS-86L358: 206Kg
VS-86L458: 237Kg
VS-86L568: 286Kg
VS-86L718: 332Kg
VS-86L838: 300Kg
NO. OF SHELVES
VS-86L108: 1
VS-86L358: 3
VS-86L458: 3
VS-86L568: 3
VS-86L718: 3
VS-86L838: 3
CLIMATE CLASS
“N”
PORTHOLE
YES
Additional features
Built-In Backup Battery
Built in battery to display
temperature when power is off.
Security
Audible and Visual Alarms.
Safety Lock.
Single LED Display
High accuracy single
LED displays.
USB Data
Built in USB Data Logger.
Data can be traced and exported.
Lockable
Additional security for
pharmaceuticals and samples.
Additional features
Built-In
Backup Battery
Built in battery to
display temperature
when power is off.
Security
Audible and Visual
Alarms. Safety Lock.
Single LED Display
High accuracy single
LED displays.
USB Data
Built in USB Data
Logger. Data can be
traced and exported.
Lockable
Additional security
for pharmaceuticals
and samples.
